At Jigna Steel (India), we pride ourselves on being a premier provider of high-quality industrial pipes and tubes designed to meet the rigorous demands of modern engineering. Our extensive inventory encompasses a wide range of specifications, including Stainless Steel, Carbon Steel, and Alloy Steel options in both seamless and welded configurations. Whether for high-pressure environments, corrosive atmospheres, or structural applications, our products are sourced and manufactured to ensure superior durability, dimensional accuracy, and long-lasting performance.
We understand that precision is paramount in sectors such as Oil & Gas, Construction, Petrochemicals, and Power Generation. Therefore, every pipe and tube supplied by Jigna Steel (India) undergoes strict quality checks to comply with international standards. Our commitment to excellence ensures that our clients receive robust piping solutions that not only fit their technical requirements but also contribute to the safety and efficiency of their operations.
Jigna Steel (India)
Leading Stockist and General Supplier specializing in high-grade Seamless & Welded Pipes and Tubes for global industrial projects.
- Available in Stainless, Carbon, and Alloy Steel
- Seamless and Welded configurations
- High corrosion and heat resistance
- Precision engineered for high-pressure use
- Strict adherence to international quality standards
Detailed Specifications
Stainless Steel
Carbon Steel
Alloy Steel
Other Materials
Types
Size
Wall Thickness
Stainless Steel Pipe Dimension & Weight Chart
Weight Calculation Formula
| Nominal | Bore | Outside Diameter | Schedule | SS | Schedule | 10S | Schedule | 20S | Schedule | 40S | Schedule | 80S | Schedule | 160S | Schedule | XXS |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| mm | inch | mm | w/t mm | weight (kg/mt) | w/t mm | weight (kg/mt) | w/t mm | weight (kg/mt) | w/t mm | weight (kg/mt) | w/t mm | weight (kg/mt) | w/t mm | weight (kg/mt) | w/t mm | weight (kg/mt) |
| 3 | 1/8 | 10.3 | 1.24 | 0.276 | 1.24 | 0.28 | 1.5 | 0.33 | 1.73 | 0.37 | 2.41 | 0.47 | - | - | - | - |
| 6 | 1/4 | 13.7 | 1.24 | 0.390 | 1.65 | 0.49 | 2.00 | 0.58 | 2.24 | 0.631 | 3.02 | 0.80 | - | - | - | - |
| 10 | 3/8 | 17.1 | 1.24 | 0.490 | 1.65 | 0.63 | 2.00 | 0.74 | 2.31 | 0.845 | 3.20 | 1.10 | - | - | - | - |
| 15 | 1/2 | 21.3 | 1.65 | 0.800 | 2.11 | 1.00 | 2.30 | 1.07 | 2.77 | 1.27 | 3.75 | 1.62 | 4.75 | 1.94 | 7.47 | 2.55 |
| 20 | 3/4 | 26.7 | 1.65 | 1.03 | 2.11 | 1.28 | 2.55 | 1.52 | 2.87 | 1.68 | 3.91 | 2.20 | 5.54 | 2.89 | 7.82 | 3.63 |
| 25 | 1 | 33.4 | 1.65 | 1.30 | 2.77 | 2.09 | 3.00 | 1.94 | 3.38 | 2.50 | 4.55 | 3.24 | 6.35 | 4.24 | 9.09 | 5.45 |
| 32 | 1.1/4 | 42.2 | 1.65 | 1.65 | 2.77 | 2.70 | 3.00 | 2.90 | 3.56 | 3.38 | 4.85 | 4.47 | 6.35 | 5.61 | 9.70 | 7.77 |
| 40 | 1.1/2 | 48.3 | 1.65 | 1.91 | 2.77 | 3.11 | 3.00 | 3.55 | 3.68 | 4.05 | 5.08 | 5.41 | 7.14 | 7.25 | 10.16 | 9.54 |
| 50 | 2 | 60.3 | 1.65 | 2.40 | 2.77 | 3.93 | 3.00 | 4.24 | 3.91 | 5.44 | 5.54 | 7.48 | 8.74 | 11.1 | 11.07 | 13.44 |
| 65 | 2.1/2 | 73.0 | 2.11 | 3.69 | 3.05 | 5.26 | 4.00 | 6.81 | 5.16 | 8.63 | 7.01 | 11.4 | 9.53 | 14.9 | 14.2 | 20.39 |
| 80 | 3 | 88.9 | 2.11 | 4.51 | 3.05 | 6.45 | 4.00 | 8.37 | 5.49 | 11.30 | 7.62 | 15.2 | 11.1 | 21.3 | 15.24 | 27.65 |
| 100 | 4 | 114.3 | 2.11 | 5.84 | 3.05 | 8.36 | 4.50 | 12.18 | 6.02 | 16.07 | 8.56 | 22.3 | 13.49 | 33.54 | 17.12 | 41.03 |
| 125 | 5 | 141.3 | 2.77 | 9.47 | 3.40 | 11.57 | 5.00 | 16.80 | 6.55 | 21.8 | 9.53 | 31.97 | 15.88 | 49.11 | 19.05 | 57.43 |
| 150 | 6 | 168.3 | 2.77 | 11.32 | 3.40 | 13.84 | 6.35 | 25.36 | 7.11 | 28.3 | 10.97 | 42.7 | 18.2 | 67.56 | 21.95 | 79.22 |
| 200 | 8 | 219.1 | 2.77 | 14.79 | 3.76 | 19.96 | 6.35 | 33.31 | 8.18 | 42.6 | 12.07 | 64.6 | 23.0 | 111.2 | 22.23 | 107.8 |
| 250 | 10 | 273.1 | 3.40 | 22.63 | 4.19 | 27.78 | 6.35 | 41.77 | 9.27 | 60.5 | 15.08 | 96.0 | 28.6 | 172.4 | 25.40 | 155.15 |
| 300 | 12 | 323.9 | 3.96 | 31.25 | 4.57 | 36.00 | 6.35 | 49.7 | 9.52 | 73.88 | 17.45 | 132.0 | 33.32 | 238.76 | 25.40 | 186.97 |
| 350 | 14 | 355.6 | 3.96 | 34.36 | 4.78 | 41.3 | 7.92 | 67.80 | 11.13 | 94.59 | 19.05 | 158.08 | 35.71 | 281.70 | - | - |
| 400 | 16 | 406.4 | 4.19 | 41.56 | 4.78 | 47.29 | 7.92 | 77.83 | 12.7 | 123.30 | 21.41 | 203.33 | 40.46 | 365.11 | - | - |
| 450 | 18 | 457.2 | 4.19 | 46.80 | 4.78 | 53.42 | 7.92 | 87.71 | 14.27 | 155.80 | 23.8 | 254.36 | 45.71 | 466.40 | - | - |
| 500 | 20 | 508.0 | 4.78 | 59.25 | 5.54 | 68.71 | 9.53 | 117.14 | 15.09 | 183.42 | 26.19 | 311.2 | 49.99 | 564.68 | - | - |
| 600 | 24 | 609.6 | 5.54 | 82.47 | 6.35 | 94.45 | 9.53 | 141.12 | 17.48 | 255.41 | 30.96 | 442.08 | 59.54 | 808.22 | - | - |
Key Note
Data includes corrected Outside Diameters (OD) and Weights (Kg/mtr) based on the density of Stainless Steel (approx. 8000 kg/m³).
